9616

Automann Bellows# : 1DK20D Bottom Part # : BS08624 Bottom Plate C to C Dia. (D) : 4.12" Bottom Plate Dia. (C) : 9.53 Bottom Plate Hole/Stud Qty : 2 Bottom Plate Type : Plastic Bracket : N/A Bumper : No Contitech Bellows# : 9 9-12 Design Height (In) : 8.00 Firestone Bellows# : 1T15L-1.5, 1T15KW-1.5 Load (Lbs) 100 PSI : 6400 Load (Lbs) 80 PSI : 5100 Max. Dia. : 11.40 Max. Height : 14.40 Min. Height : 3.90 Natural Freq. (CPM) : 80 Top Plate Dia. (A) : 9.00 Top Plate Hole/Stud Qty : 2 Triangle Bellows# : 6368 Type : Rolling Lobe Part number: AB1DK20D-9616 OE MFG: Contitech OEM Reference: 9 9-12 P 515 Cross Reference: CONTITECH : 64256, 69655, 9 9-12 P 515; FIRESTONE : 9616, 9673, W013589616, W01-358-9616, W015449616, W01-544-9616, W015449673, W01-544-9673; GOODYEAR : 1R11242, 1R11-242; KENWORTH : K30316, K303-16, K-303-16 |

Air Spring;Rlob/P Air Spring Type : Rolling Lobe Bellows Color : Black Bellows Material : Rubber Bottom Plate Bolt Hole Quantity : 2 Bottom Plate Diameter : 9.5 in Grade Type : Standard Replacement Maximum Height : 12.99 in Minimum Height : 4.33 in Mounting Hardware Included : No Mounting Stud Quantity : 2 Package Contents : 1 Air Spring Packaging Type : Box Part Number : 452-9616 Part Type : Suspension - Air Spring Piston Material : Plastic Selling Package Quantity : 1 Selling Package Quantity UOM : EA Top Plate Bolt Hole Quantity : 2 Top Plate Diameter : 9 in Weight : 12.200000 Part number: 452-9616 Cross Reference: VMRS : 016008001; OTHER : 1R11242, 1R11-242, 64256, 9616, AB1DK20D9616, AB1DK20D-9616, AB9616, AB-9616, AS8515, AS-8515, AS9616, AS96160, MAF9616, TR9616 Product Class: Suspension - Air Spring

Air Spring;Rlob/P Air Spring Type : Rolling Lobe Bellows Color : Black Bellows Material : Rubber Bellows Material Thickness : 1 in Bottom Plate Bolt Hole Quantity : 2 Bottom Plate Diameter : 9.5 in Grade Type : Standard Replacement Maximum Height : 12.99 in Minimum Height : 4.33 in Mounting Hardware Included : No Mounting Stud Quantity : 2 Package Contents : 1 Air Spring Packaging Type : Box Part Number : 452-9616L Part Type : Suspension - Air Spring Piston Material : Plastic Selling Package Quantity : 1 Selling Package Quantity UOM : Piece Top Plate Bolt Hole Quantity : 2 Top Plate Diameter : 9 in Weight : 11.990000 Part number: 452-9616L Cross Reference: VMRS : 016008001; OTHER : 1R11242, 1R11-242, 4529616, 452-9616, 4529616L, 452-9616L, 64256, 9616, 9912P515, AB1DK20D9616, AB1DK20D-9616, AS8515, AS-8515, AS9616, AS96160, FS9616, GFAB9616, MAF9616, TR9616, W013589616 Product Class: Suspension - Air Spring

Air Spring W013589616 Air Spring Type : Rolling Lobe Bellows Color : Black Bellows Material : Rubber Bottom Plate Bolt Hole Quantity : 2 Bottom Plate Diameter : 9.5 in Flexmember (Bellows Number) : 1T15L-1.5 Grade Type : Standard Manufacturer : Firestone Maximum Height : 13.3 in Minimum Height : 3.8 in Mounting Hardware Included : Yes Mounting Stud Quantity : 2 Package Contents : 1 Air Spring Packaging Type : Box Part Number : 352-9616 Part Type : Suspension - Air Spring Piston Material : Plastic Selling Package Quantity : 1 Selling Package Quantity UOM : EA Top Plate Bolt Hole Quantity : 2 Top Plate Diameter : 9 in Weight : 11.230000 Part number: 352-9616 Cross Reference: VMRS : 016008001; PACCAR : K30316, K303-16; OTHER : 1R11242, 1R11-242, 1T15L15, 1T15L1.5, 64256, 9616, 9912P515, AB1DK20D9616, AB1DK20D-9616, AS8515, AS-8515, FS9616, PW013589616, TR9616, W013589616 Product Class: Suspension - Air Spring

Clamp Clamping Type : V Band Color : Silver Finish : Aluminized Grade Type : Premium Material : Aluminized Steel Package Contents : 1 Clamp Part Number : 674-9656 Part Type : Exhaust Clamp Performance Rated : No Pipe Diameter : 5 in Quantity : 1 Selling Package Quantity : 1 Selling Package Quantity UOM : EA Size : 5 in Thread Diameter : 1/4 in Thread Length : 1.5 in Universal Or Specific Fit : Specific Weight : 0.380000 Part number: 674-9656 Cross Reference: VMRS : 043003013; DAYTON PARTS : W35500; OTHER : 21192, 21-192, 2500970, 250-0970, 35500, 40450S, 40-450S, 89510K, 9616, P210110, UV500 Product Class: Exhaust Clamp

1T15L1.5 ST1/4NPT BRKT PST
