9466

Air Spring;Rlob/P Air Spring Type : Rolling Lobe Bellows Color : Black Bellows Material : Rubber Bottom Plate Bolt Hole Quantity : 2 Bottom Plate Diameter : 10 in Grade Type : Standard Replacement Maximum Height : 14.96 in Minimum Height : 8.27 in Mounting Hardware Included : No Mounting Stud Quantity : 2 Package Contents : 1 Air Spring Packaging Type : Box Part Number : 452-9466 Part Type : Suspension - Air Spring Piston Material : Plastic Selling Package Quantity : 1 Selling Package Quantity UOM : EA Top Plate Bolt Hole Quantity : 2 Top Plate Diameter : 8.98 in Weight : 13.600000 Part number: 452-9466 Cross Reference: VMRS : 016008001; OTHER : 1R12365, 1R12-365, 64276, 9466, AB1DK23K9466, AB1DK23K-9466, AS8410, AS-8410, AS9466, AS94660, TR9466 Product Class: Suspension - Air Spring

Automann Bellows# : 1DK23K Bottom Part # : BS08662 Bottom Plate C to C Dia. (D) : 4.50" Bottom Plate Dia. (C) : 10.00 Bottom Plate Hole/Stud Qty : 2 Bottom Plate Type : Plastic Bracket : N/A Bumper : Yes Contitech Bellows# : 9 10-16 Design Height (In) : 11.00 Firestone Bellows# : 1T15M-6 Goodyear Bellows# : 566-24-3-038 Load (Lbs) 100 PSI : 7500 Load (Lbs) 80 PSI : 5900 Max. Dia. : 12.60 Max. Height : 20.70 Min. Height : 8.00 Natural Freq. (CPM) : 64 Top Plate C to C Dia. (B) : 6.20 Top Plate Dia. (A) : 9.00 Top Plate Hole/Stud Qty : 2 Triangle Bellows# : 6363 Type : Rolling Lobe Part number: AB1DK23K-9466 OE MFG: Contitech OEM Reference: 9 10-16 P 410 Cross Reference: CONTITECH : 161022, 64276, 9 10-16 P 410; FIRESTONE : 9466, W013589466, W01-358-9466, W014559466, W01-455-9466; FORD : E9HZ5580A; GOODYEAR : 1R12197, 1R12-197, 1R12365, 1R12-365; HENDRICKSON : 49048, 49048002, 49048-002, 49048002L, 49048-002L, 490482, 49048-2, 49207, 496741, 49674-1, 496742, 49674-2; HENDRICKSON DISTRIBUTION CENTER : 49048, 49048-002, 49048-002L, 49048-2, 49674; LOADGUARD : SC2175; MACK : 25119882, 364QS28, 364SQ28, 4000-49048, 4000-49048002L, 4000-49674, 49674-2, 57QL411M, 8633-1R12365; VOLVO/WHITE : 350033805, 35003-3805, 350034409, 85101157 | PAI : 0681, 750298

Air Spring;Rlob/P Air Spring Type : Rolling Lobe Bellows Color : Black Bellows Material : Rubber Bellows Material Thickness : 1 in Bottom Plate Bolt Hole Quantity : 2 Bottom Plate Diameter : 10 in Grade Type : Standard Maximum Height : 14.96 in Minimum Height : 8.27 in Mounting Hardware Included : No Mounting Stud Quantity : 2 Package Contents : 1 Air Spring Packaging Type : Box Part Number : 452-9466L Part Type : Suspension - Air Spring Piston Material : Plastic Selling Package Quantity : 1 Selling Package Quantity UOM : Piece Top Plate Bolt Hole Quantity : 2 Top Plate Diameter : 8.98 in Weight : 16.000000 Part number: 452-9466L Cross Reference: VMRS : 016008001; OTHER : 1R12365, 1R12-365, 4529466, 452-9466, 4529466L, 452-9466L, 64276, 91016P410, 9466, AB1DK23K9466, AB1DK23K-9466, AS0140, AS-0140, AS8410, AS-8410, AS8442, AS-8442, AS9466, AS94660, FS9466, M3526, M-3526, TR9466, W013589466 Product Class: Suspension - Air Spring

Technical specification:- Length 210 mm- Outer diameter 82 mm- Inner diameter 35 mm(If the product is replaced with product TF4159, nipple FT5116767 and filter base FT5129631 are needed)

Air Spring Air Spring Type : Rolling Lobe Bellows Color : Black Bellows Material : Rubber Bottom Plate Bolt Hole Quantity : 2 Bottom Plate Diameter : 10 in Div : TRK Grade Type : Standard Replacement Manufacturer : Hendrickson Maximum Height : 20 in Minimum Height : 8.1 in Mounting Hardware Included : No Mounting Stud Quantity : 2 Mrk : 28 Notes : Combo Stud+1/2"stud Top Package Contents : 1 Air Spring Packaging Type : Box Part Number : 49048-002L Part Type : Suspension - Air Spring Piston Material : Plastic Selling Package Quantity : 1 Selling Package Quantity UOM : EA Top Plate Bolt Hole Quantity : 2 Top Plate Diameter : 9 in Weight : 16.600000 Part number: 49048-002L Cross Reference: VMRS : 016008001; OTHER : 049048002L, 049048-002L, 49048002, 49048-002, 49048002L, 49048-002L, 490482, 49048-2, 9466, AS9466 Product Class: Suspension - Air Spring

Hendrickson Rear HA, HAS 360/400/402/460/40LH (HAS 120/150/190/210/230)

Air Spring Rolling Lobe Maximum Height: 20.60in Minimum Height: 8.10in Mack early CH model application Part number: FAS-0681 OE MFG: MACK OEM Reference: 57QL411M Cross Reference: CONTITECH : 161022, 64276, 9 10-16 P 410; FIRESTONE : 9466, W013589466, W014559466; FORD : E9HZ5580A; GOODYEAR : 1R12197, 1R12365; HENDRICKSON : 49048, 49048002, 49048002L, 490482, 49207, 496741, 496742; HENDRICKSON DISTRIBUTION CENTER : 49048, 49048-002, 49048-002L, 49048-2, 49674; LOADGUARD : SC2175; MACK : 25119882, 364QS28, 364SQ28, 4000-49048, 4000-49048002L, 4000-49674, 49674-2, 57QL411M, 8633-1R12365; VOLVO/WHITE : 350033805, 350034409, 85101157; OTHER : 1R12-197, 1R12-365, 8410, E-FS9466 | AUTOMANN : AB1DK23K-9466; PAI : 750298 Product Class: Air Springs
