64375

Dimensions (mm):- D1 47- D2 47- D3 46- H1 49- H2 1- H3 1

Automann Bellows# : 1DK20E Bottom Part # : BS14115 Bottom Plate C to C Dia. (D) : 4.12" Bottom Plate Dia. (C) : 10.00 Bottom Plate Hole/Stud Qty : 2 Bottom Plate Type : Plastic Bracket : N/A Bumper : Yes Contitech Bellows# : 9 9-14 Design Height (In) : 12.00 Firestone Bellows# : 1T15L-4 Goodyear Bellows# : 566-22-3-006 Load (Lbs) 100 PSI : 8670 Load (Lbs) 80 PSI : 6930 Max. Dia. : 11.70 Max. Height : 18.20 Min. Height : 7.20 Natural Freq. (CPM) : 81 Top Plate C to C Dia. (B) : 4.75 Top Plate Dia. (A) : 9.00 Top Plate Hole/Stud Qty : 2 Type : Rolling Lobe Part number: AB1DK20E-9415 OE MFG: Bluebird Bus OEM Reference: 0990671 Cross Reference: BLUEBIRD BUS : 0990671; CONTITECH : 64375, 64378, 9 10D-21 A 324, 9 9-14 P 322; FIRESTONE : 9250, 9415, FS9073, W013589250, W013589415, W01-358-9415, W015449200, W01-544-9200; GOODYEAR : 1R11018, 1R11-018, 1R11051, 1R11-051, 1R13115; GRANNING : 6427; HENDRICKSON TRAILER : B-7193, S13040, S-13040; IHC : 554761C1; KENWORTH : K3035, K-303-5; LOADGUARD : SC2049; NEWAY : 57009250; RIDEWELL : 1003589250C, 1003589415C; SAF HOLLAND : 57009415; WATSON&CHALIN : AS0096 | AUTOMANN : AB1DK23S-9250

Automann Bellows# : 1DK23S Bottom Part # : BS11399 Bottom Plate C to C Dia. (D) : 7.87" Bottom Plate Dia. (C) : 9.75 Bottom Plate Hole/Stud Qty : 4 Bottom Plate Type : Aluminum Bracket : N/A Bumper : Yes Contitech Bellows# : 9 10D-21 Design Height (In) : 18.00 Firestone Bellows# : 1T15V-11 Goodyear Bellows# : 566-26-3-044 Load (Lbs) 100 PSI : 8100 Load (Lbs) 80 PSI : 6400 Max. Dia. : 13.70 Max. Height : 26.90 Min. Height : 9.70 Natural Freq. (CPM) : 56 Top Plate C to C Dia. (B) : 5.50 Top Plate Dia. (A) : 9.00 Top Plate Hole/Stud Qty : 2 Triangle Bellows# : 6371 Type : Rolling Lobe Part number: AB1DK23S-9250 OE MFG: Contitech OEM Reference: 9 10D-21 A 324 Cross Reference: BLUEBIRD BUS : 0990671; CONTITECH : 64375, 64378, 9 10D-21 A 324, 9 9-14 P 322; FIRESTONE : 9250, 9415, FS9073, W013589250, W01-358-9250, W013589415, W015449200; GOODYEAR : 1R11018, 1R11051, 1R13115, 1R13-115; GRANNING : 6427; HENDRICKSON TRAILER : B-7193, S13040; IHC : 554761C1; KENWORTH : K3035; LOADGUARD : SC2049; NEWAY : 57009250; RIDEWELL : 1003589250C, 1003589415C; SAF HOLLAND : 57009415; WATSON&CHALIN : AS0096, AS-0096 | AUTOMANN : AB1DK20E-9415
